Maintenance
111
Pull out and release the lock for the guard.
Open the machine's front guard.
Turn the cutting discs by hand until the damaged knife is in the
position shown.
Use a suitable tool to remove the bolt.
The minimum diameter of the bolt must not be less than φ16 mm (
5
/
8
’’).
Replace the knife and fit the bolt.
Use a torque wrench to tighten the bolt to the torque shown.
Minimum
φ16 mm (φ
5
/8”)
95 Nm +/- 5
(70 ft/ lb. +/- 4)
