Maintenance
118
Pull out and release the lock for the guard.
Open the machine's front guard.
Fit the guard around the PTO shaft between the transmission and
the cutterbar.
Remove the bolts and replace the PTO shaft.
Clean the bolts.
Apply Loctite 242 or a similar product to all bolts.
Fit the bolts and tighten to the torque shown.
Fit the guard around the PTO shaft between the transmission and
the cutterbar.
