Maintenance
71
Locate the oilplug on the left side of the cutterbar and remove it.
• With warm oil: Wait approximately 3 minutes
• With cold oil: Wait approximately 15 minutes
Check the oil level as shown and refill if necessary.
• Min. 6 mm (
1
/
4
’’)
• Max. 9 mm (
3
/
8
’’)
→ »Lubricants« page 134
Fit the oilplug and tighten it fully.
Pull out and release the lock for the guard.
Close the machine's front guard.
Open the mechanical safety valve.
