Maintenance
133
Fit the guard.
Centre gear
Changing oil
After 10 working hours
Thereafter, every season
CT model only
Type 1
»Maintenance intervals« page 79
Oil amount when changing oil:
The oil is changed as follows:
Use a suitable tool to remove the oilplug 3.
Let the oil run into an appropriate reception container.
Allow the last of the oil to drip out of the transmission for approx.
10 - 15 minutes.
Fit oilplug 3 and tighten it.
Remove oilplug 1.
Remove oilplug 2.
Fill the new oil through the hole for oilplug 1.
• The correct oil level is reached when the oil reaches the edge of
the hole for oilplug 2.
Fit oilplugs 1 and 2 and tighten them.
»Lubricants« page 170
Litre
(approx.)
Pints (US)
(approx.)
Pints (Imp.)
(Approx.)
1.5 3.2 2.6
Oilplug 3
Oilplug 2
Oilplug 1
