Viessmann VITOGAS - Delivered Condition; Vitotronic 150, Type KB2, Part No. 7186 570; Specification

Programming unit:
■ Display
■ Keys:
– Program selection
– Boiler water temperature
– DHW temperature
Functions
■ Constant control of the boiler water temperature
■ Electronic maximum and minimum temperature limit
■ Integral diagnostic system
■ Cylinder temperature control unit with priority control (heating circuit
pump OFF).
According to the [German] Energy Savings Order, a weather-com-
pensated or room temperature-dependent control unit with time pro-
gramming for reduced operation must be installed downstream of the
boiler (see Viessmann pricelist register 18 "Heating circuit control
units").
Control characteristics
■ P-characteristics with two-point output
■ Thermostat for limiting the max. boiler water temperature:
75 °C, adjustable to 87 °C or 95 °C
■ Adjusting the high limit safety cut-out:
110 °C, adjustable to 100 °C
Boiler coding card
For matching to the boiler (supplied with the boiler).
Specification
Rated voltage 230 V~
Rated frequency 50 Hz
Rated current 6 A
Power consumption 5 W
Protection class I
IP rating IP 20 D to EN 60529;
ensure through appro-
priate design and instal-
lation
Function Type 1B to
EN 60 730-1
Permissible ambient temperature
– during operation 0 to +40 °C
Installation in living
spaces or boiler rooms
(standard ambient con-
ditions)
– during storage and transport -20 to +65 °C
Rated capacity of the relay outputs
sÖ
Heating circuit pump
4(2) A 230 V~
sA
Circulation pump for cylinder heat-
ing
4(2) A 230 V~
Total sÖ, sA
max. 4 A, 230 V~
fA
Burner 4(2) A 230 V~
lÖ
Burner, two-stage
Only with auxiliary module (part of the
standard delivery for Viessmann boil-
ers)
1(0.5) A 230 V~
Total 6 A 230 V~
Delivered condition
■ Boiler water temperature sensor
■ Cylinder temperature sensor
■ Bag with technical documentation
Heating system with DHW cylinder
Order the circulation pump with check valve for cylinder temperature
control separately.
6.5 Vitotronic 150, type KB2, part no. 7186 570
Specification
Construction
The control unit comprises a standard unit, electronic modules and a
programming unit.
Standard unit:
■ ON/OFF switch
■ Terminals for high limit safety cut-out test
■ Keys for emissions test function
■ Optolink laptop interface
■ Temperature controller
DIN TR 77708
or
DIN TR 116807
■ High limit safety cut-out
DIN STB 106005
or
DIN STB 116907
■ Operation and fault displays
■ Plug connection chamber:
– Connection of external equipment via a system plug
– Connection of three-phase consumers via additional contactors
Programming unit:
■ With digital multi-channel time switch
■ Adjustment and display of temperatures and codes
■ Fault message display
■ Rotary selector for the temperature in standard mode
■ Keys:
– Temperature for reduced mode
– Program selection
– Boiler water temperature
– DHW temperature
■ Time / Date
Functions
■ Heat demand-dependent control of the boiler water temperature
■ Electronic maximum and minimum temperature limit
■ Anti-seizing pump protection
■ Integral diagnostic system
■ Adaptive cylinder temperature control unit with priority control (heat-
ing circuit pumps OFF)
According to the Energy Savings Order [Germany], the temperature in
each room must be individually controlled, e.g. through thermostatic
radiator valves.
Control units
(cont.)
