For heating systems with several heating circuits we recommend the
use of other boiler and heating circuit control units (e.g. Vitotronic 200
or Vitotronic 300).
Control characteristics
■ P-characteristics with two-point output
■ Thermostat for limiting the max. boiler water temperature:
75 °C, adjustable to 87 °C or 95 °C
■ Adjusting the high limit safety cut-out:
110 °C, adjustable to 100 °C
Time switch
Digital multi-channel time switch
■ Day and week program, annual calendar
■ Automatic summer/winter time changeover
■ Time, day and standard switching times for central heating and DHW
heating are factory-set
■ Switching times are individually programmable, i.e. up to four switch-
ing periods per day
Shortest switching interval: 10 minutes
Power backup: 5 years
Boiler coding card
For matching to the boiler (supplied with the boiler).
Setting heating programs
The heating system frost protection (see frost protection function)
applies to all heating programs.
You can select the following operating programs with the program
keys:
■ Heating and DHW
■ Only DHW
■ Standby mode
Standby mode
No DHW heating takes place in "Standby mode".
In summer, the burner is switched ON if the boiler water temperature
reaches 5 °C and is switched OFF again when the boiler water tem-
perature reaches 42 °C.
The heating circuit pump will be switched OFF from 16 March to
15 October.
From 16 October to 15 March it will then be switched ON on
demand.
Summer mode
("DHW only")
The burner starts only when the DHW cylinder needs reheating (con-
trolled by the cylinder thermostat).
The respective lower boiler water temperature of each boiler is main-
tained.
Specification
Rated voltage 230 V~
Rated frequency 50 Hz
Rated current 6 A
Power consumption 5 W
Protection class I
IP rating IP 20 D to EN 60529;
ensure through appro-
priate design/installa-
tion
Function Type 1B to
EN 60 730-1
Permissible ambient temperature
– during operation 0 to +40 °C
Installation in living
spaces or boiler rooms
(standard ambient con-
ditions)
– during storage and transport
−20 to +65 °C
Rated capacity of the relay outputs
sÖ
Heating circuit pump
4(2) A 230 V~
sA
Circulation pump for cylinder heat-
ing
4(2) A 230 V~
Total sÖ, sA
max. 4 A, 230 V~
fA
Burner 4(2) A 230 V~
Total 6 A 230 V~
Delivered condition
■ Boiler water temperature sensor
■ Cylinder temperature sensor
■ Bag with technical documentation
Heating system with DHW cylinder
Order the circulation pump with check valve for cylinder temperature
control separately.
6.6 Vitotronic 200, type KW4, part no. 7186 571
Specification
Construction
The control unit comprises a standard unit, electronic modules and a
programming unit.
Standard unit:
■ ON/OFF switch
■ Terminals for high limit safety cut-out test
■ Keys for emissions test function
■ Optolink laptop interface
■ Temperature controller
DIN TR 96808
or
DIN TR 116807
■ High limit safety cut-out
DIN STB 106005
or
DIN STB 98108
or
DIN STB 116907
■ Operation and fault displays
■ Plug connection chamber
– Connection of external equipment via a system plug
– Connection of three-phase consumers via additional contactors
Programming unit:
■ With digital time switch
■ Backlit display with plain text support
■ Adjustment and display of temperatures and codes
■ Fault message display
■ Rotary selector for the temperature in standard mode
■ Keys:
– Temperature for reduced mode
– Program selection
– Holiday program
– Party and economy mode
– DHW temperature
– Heating curves for boiler water temperature and flow temperature
– Time / Date
Control units
(cont.)
VITOGAS
VIESMANN
51
5822 428 GB
6
