3.1 Specification Vitocell 100-V, type CVA
For DHW heating in conjunction with boilers and district heating sys-
tems, as option with electric heater as accessory for DHW cylinders
with 300 and 500 l capacity.
Suitable for the following systems:
■ DHW temperatures up to 95 °C
■ Heating water flow temperature up to 160 °C
■ Operating pressure on the heating water side up to 25 bar
■ Operating pressure on the DHW side up to 10 bar
Capacity l 160 200 300 500 750 1000
DIN reg. no. 0241/06–13 MC/E
Continuous output
for DHW heating from 10 to 45 °C
and a heating water flow tempera-
ture of ... at the heating water
throughput stated below
90 °C kW 40 40 53 70 123 136
l/h 982 982 1302 1720 3022 3341
80 °C kW 32 32 44 58 99 111
l/h 786 786 1081 1425 2432 2725
70 °C kW 25 25 33 45 75 86
l/h 614 614 811 1106 1843 2113
60 °C kW 17 17 23 32 53 59
l/h 417 417 565 786 1302 1450
50 °C kW 9 9 18 24 28 33
l/h 221 221 442 589 688 810
Continuous output
for DHW heating from 10 to 60 °C
and a heating water flow tempera-
ture of ... at the heating water
throughput stated below
90 °C kW 36 36 45 53 102 121
l/h 619 619 774 911 1754 2081
80 °C kW 28 28 34 44 77 91
l/h 482 482 584 756 1324 1565
70 °C kW 19 19 23 33 53 61
l/h 327 327 395 567 912 1050
Heating water flow rate for the stated contin-
uous outputs
m
3
/h
3.0 3.0 3.0 3.0 5.0 5.0
Standby heat loss q
BS
at a temp. differential of 45 K (actual value acc.
to DIN 4753-8.
500 l: Standard parameter to DIN V 18599)
kWh/
24 h
1.50 1.70 2.20 3.20 3.70 4.30
Thermal insulation Rigid PUR foam Flexible polyurethane foam
Dimensions
Length (7)
– incl. thermal insulation a mm 581 581 633 850 960 1060
– excl. thermal insulation mm — — — 650 750 850
Width
– incl. thermal insulation b mm 608 608 705 898 1046 1144
– excl. thermal insulation mm — — — 837 947 1047
Height
– incl. thermal insulation c mm 1189 1409 1746 1955 2100 2160
– excl. thermal insulation mm — — — 1844 2005 2060
Height of unit when tilted
– incl. thermal insulation mm 1260 1460 1792 — — —
– excl. thermal insulation mm — — — 1860 2050 2100
Installation height mm — — — 2045 2190 2250
Weight including thermal insulation kg 86 97 151 181 295 367
Heating water content l 5.5 5.5 10.0 12.5 24.5 26.8
Heating surface
m
2
1.0 1.0 1.5 1.9 3.7 4.0
Connections
Heating water flow and return R 1" 1" 1" 1" 1¼" 1¼"
Cold water, DHW R ¾" ¾" 1" 1¼" 1¼" 1¼"
DHW circulation R ¾" ¾" 1" 1" 1¼" 1¼"
Information regarding continuous output
When designing the system for continuous output as stated or calcu-
lated, allow for the corresponding circulation pump. The stated con-
tinuous output is only achieved when the rated boiler output
≥
contin-
uous output.
DHW cylinder
(cont.)
VITOGAS
VIESMANN
17
5822 428 GB
3
