For Vitocell 100-H/300-H, see pages 27 and 30. Only possi-
ble for those combinations specified in the pricelist.
E Drain and diaphragm expansion vessel
GA Gas connection
KR Boiler return
KV Boiler flow
SSI Draught hood
SV Safety flow
Pressure drop (primary circuit)
The Vitogas 200-F is only suitable for fully pumped hot water heating
systems.
1
2
3
4
5
6
8
10
20
30
40
50
300 400 500 600
800
1000 2000 3000 4000 5000 6000 8000
Pressure drop in mbar
Throughput in l/h
C
EA
B D
A
Rated output 11 and 15 kW
B
Rated output 18 and 22 kW
C
Rated output 29 kW
D
Rated output 35 and 42 kW
E
Rated output 48 and 60 kW
Product information
(cont.)
