25
Outside temperature sensor or room temperature sensor
(accessories)
1. Fit the temperature sensor.
Outside temperature sensor instal-
lation location:
■ North or north-westerly wall, 2 to
2.5 m above ground level; in
multi storey buildings, in the
upper half of the second floor
■ Not above windows, doors or
vents
■ Not immediately below balconies
or gutters
■ Never render over
■ Connection:
2-core lead for low voltage,
length up to 35 m
2. Plug the connecting cable supplied
into slot "X7".
3. Connect the temperature sensor to
terminals 3 and 4 (see page 24).
4. Set the function of the sensor at the
control unit during commissioning
(see page 38).
For function description see page 84.
Installation sequence
Electrical connections
(cont.)
5837146
Installation
