6. Place the remaining Cabinets up onto the Wall Mount Brackets. Install from
boom to top, ensuring the Mounng Brackets sit securely on the Wall Mount
Brackets.
7. Repeat Step 4, securing the cabinets together with each Locking Bolt and Hook.
Push the Locking Bolt.
Lock each Hook with the hex tool.
NOTE:
There are ve (5)
Locking Bolts
and 10
Hooks
between each cabinet.
8. Further secure the Cabinets together with M6x16mm screws.
