3. You can also reroute the power cable for cable management. Loosen the two (2)

PWM 4x6mm screws, pull the power cable out, thread the power cable through

the hole and then fasten the screws ghtly.

Hole for cable management

Two (2) PWM 4x6mm Screws

Professional installaon only.
