ViewSonic PJD5112 Service Manual

Operation Function Troubleshooting
Remote Control
Failure
Replace
Battery
Replace
Remote Control
Replace
IR
Replace
Main board
OK
OK
OK
NG
NG
NG
NG
Check
Main board
Check
Remote Control
Check
Battery Level
Check
IR
Button Failure
Replace Keypad
and FFC
Replace
Main board
NG
NG
OK
Check
Main board
Check
Keypad and FFC
ViewSonicCorporation Confidential - Do Not Copy PJD5112
33

ViewSonic PJD5112 Specifications

General

Projection distance	1.2 - 10 m
Projection technology	DLP
Contrast ratio (typical)	2000:1
Projector native resolution	SVGA (800x600)
Aspect ratio	4:3, 16:9
RS-232 ports	1
Dimensions (WxDxH)	280 x 218 x 114 mm
Power requirements	90~240VAC
Lamp power	180 W
Light source type	Lamp
Service life of light source	3000 h
Service life of light source (economic mode)	5000 h
Focus	Manual
RMS rated power	2 W
Headphone outputs	2
Serial interface type	RS-232
Noise level	30 dB
Power consumption (standby)	1 W
Power consumption (typical)	235 W
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Product type	Standard throw projector
Market positioning	Presentation

Weight and Dimensions

Weight	2600 g
