5 Connector Information
This section provides each connector location on boards and function of each board. They will
be useful for your detecting the defective boards.
5.1 Main Board
Connector Description
No 1 Front IR
No 2 Connect to RS232 Board
5.2 The backside of Main Board
No1
No2
No4
No6
No8
No9
No10
No11
No12
No13No14
No3
No5
No7
