ViewSonic PJD5112 Service Manual

Appendix A: RS-232 Command and Configuration
Baud Rate: 19200 Parity Bit: none
Data Bit: 8 Stop Bit: 1 Assign Port: COM1
Name Operation type CRS Header Command Response
ON BE,EF,10,05,00 C6,FF 11,11,01,00,01,00 06
Power
OFF BE,EF,03,06,00 DC,DB 69,00,00,00,00,00 06
Computer
(Analog RGB) BE,EF,03,19,00 19,29 01,47,05,CC,CC,00 06
YCbCr BE,EF,03,19,00 89,E8 01,47,05,CC,CC,00 06
S-Video BE,EF,03,19,00 E8,69 01,47,05,CC,CC,00 06
Composite
Video BE,EF,03,19,00 78,A8 01,47,05,CC,CC,00 06
Source
HDTV (Y-Pb-Pr)
BE,EF,03,19,00 DA,A8 01,47,05,CC,CC,00 06
Menu BE,EF,02,06,00 E9,D3 30,00,00,00,00,00 06
Up BE,EF,02,06,00 6D,D2 34,00,00,00,00,00 06
Down BE,EF,02,06,00 0B,D2 32,00,00,00,00,00 06
Left BE,EF,02,06,00 DA,D3 33,00,00,00,00,00 06
OSD
Right BE,EF,02,06,00 38,D2 31,00,00,00,00,00 06
On BE,EF,03,06,00 EF,DB 6A,00,00,00,00,00 06
ECO
Off BE,EF,03,06,00 3E,DA 6B,00,00,00,00,00 06
On BE,EF,03,06,00 89,DB 6C,00,00,00,00,00 06Auto
Source
Off BE,EF,03,06,00 58,DA 6D,00,00,00,00,00 06
Source BE,EF,02,06,00 57,D0 2E,00,00,00,00,00 06
Auto-Sync BE,EF,02,06,00 86,D1 2F,00,00,00,00,00 06
Blank Screen(Video) BE,EF,02,06,00 DF,DF 66,00,00,00,00,00 06
Keystone BE,EF,02,06,00 3D,DE 64,00,00,00,00,00 06
Up BE,EF,03,06,00 10,DB 65,00,00,00,00,00 06
Keystone
Down BE,EF,03,06,00 23,DB 66,00,00,00,00,00 06
Volume + BE,EF,02,06,00 F1,DE 68,00,00,00,00,00 06
Volume
Volume - BE,EF,02,06,00 20,DF 69,00,00,00,00,00 06
Image BE,EF,03,06,00 F2,DA 67,00,00,00,00,00 06
Aspect Ratio BE,EF,03,06,00 0D,DA 68,00,00,00,00,00 06
Factory Reset BE,EF,03,06,00 6B,DA 6E,00,00,00,00,00 06
Lamp Hour BE,EF,03,06,00 BA,DB 6F,00,00,00,00,00 Lamp Hour
Firware Version BE,EF,03,06,00 D5,D9 70,00,00,00,00,00 Version
ViewSonicCorporation Confidential - Do Not Copy PJD5112
51

ViewSonic PJD5112 Specifications

General

Projection distance	1.2 - 10 m
Projection technology	DLP
Contrast ratio (typical)	2000:1
Projector native resolution	SVGA (800x600)
Aspect ratio	4:3, 16:9
RS-232 ports	1
Dimensions (WxDxH)	280 x 218 x 114 mm
Power requirements	90~240VAC
Lamp power	180 W
Light source type	Lamp
Service life of light source	3000 h
Service life of light source (economic mode)	5000 h
Focus	Manual
RMS rated power	2 W
Headphone outputs	2
Serial interface type	RS-232
Noise level	30 dB
Power consumption (standby)	1 W
Power consumption (typical)	235 W
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Product type	Standard throw projector
Market positioning	Presentation

Weight and Dimensions

Weight	2600 g
