ViewSonic PJD5112 Service Manual

Item ViewSonic P/N Ref. P/N Description Q'ty
1 C-00009804 P6L84-4500 Top Cover 1
2 C-00009638 P4E34-4650-00 Lens Cover 1
3 C-00009633 P4S84-4530 IO Cover 1
4 C-00009630 P4R84-4520 Lamp Cover 1
5 C-00009635 P4R34-4600-00 Filter Cover 1
6 C-00009634 P4R34-4570-00 Lens Housing 1
7 RLC-050 P4R84-2400 Lamp Module 1
8 E-00009672 P6L84-2200 Optical Engine 1
9 B-00009850 P6L84-7100 Main Board 1
10 B-00009701 P4R47-6101 RS232 Board 1
11 B-00009703 P4D47-6100 DMD Board 1
12 B-00008158 P3747-5101 FIR Board 1
13 B-00009700 P4R47-5101 BIR Board 1
14 B-00009702 P4R84-9000 Ballast 1
15 E-00009495 J2413-0092-00 Speaker 1
16 M-00008342 J2394-0101-01 Fan2 1
17 M-00008212 J2394-0101-00 Fan1 1
18 B-00009698 P4U84-8100 Power Board 1
19 C-00009632 P4R84-4510 Bottom Cover 1
20 M-00008344 P4E38-1570-00 Rear Foot 1
EXPLODED PARTS LIST (PJD5112 )
ViewSonic Model Number: VS12618
Rev: 1a
ViewSonicCorporation Confidential - Do Not Copy PJD5112
45

ViewSonic PJD5112 Specifications

General

Projection distance	1.2 - 10 m
Projection technology	DLP
Contrast ratio (typical)	2000:1
Projector native resolution	SVGA (800x600)
Aspect ratio	4:3, 16:9
RS-232 ports	1
Dimensions (WxDxH)	280 x 218 x 114 mm
Power requirements	90~240VAC
Lamp power	180 W
Light source type	Lamp
Service life of light source	3000 h
Service life of light source (economic mode)	5000 h
Focus	Manual
RMS rated power	2 W
Headphone outputs	2
Serial interface type	RS-232
Noise level	30 dB
Power consumption (standby)	1 W
Power consumption (typical)	235 W
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Product type	Standard throw projector
Market positioning	Presentation

Weight and Dimensions

Weight	2600 g
