ViewSonic PJD5112 Service Manual

Item ViewSonic P/N Ref. P/N Description Q't
y
1 DC-00008697 P1638-5007-00 LB 1
2 DC-00008696 P2838-5001-00 WARNING LB 1
3 DC-00008692 P1638-5010-00 LB 1
4
N
A J4238-R815-01 SERIAL LB 1
5
N
A P4S38-5000-00 UL LB 1
6 DC-00008693 P1238-R504-00 LB 1
7 P-00009637 P4R39-7001-00 EPE 1
8&16 P-00009811 P6L39-6000-00 CARTON 1
9 P-00008880 J4039-R128-01 DESICCANT 1
10 M-00008389 P8339-6900-00 PAD 1
11
N
A P4R39-4800-00 SHEET 1
12 DC-00009914 P6L39-4000-00 QG 1
13 DC-00009915 P6L39-A000-00 CD-ROM 1
14 P-00008410 J4039-R157-01 PE.BAG 1
15 P-00008794 J4039-R184-01 PE.BAG 1
17 DC-00009031 J4238-5006-00 LB 1
ViewSonic Model Number: VS12618
Rev: 1a
PACKING PART LIST ( PJD5112 )
ViewSonicCorporation Confidential - Do Not Copy PJD5112
48

ViewSonic PJD5112 Specifications

General

Projection distance	1.2 - 10 m
Projection technology	DLP
Contrast ratio (typical)	2000:1
Projector native resolution	SVGA (800x600)
Aspect ratio	4:3, 16:9
RS-232 ports	1
Dimensions (WxDxH)	280 x 218 x 114 mm
Power requirements	90~240VAC
Lamp power	180 W
Light source type	Lamp
Service life of light source	3000 h
Service life of light source (economic mode)	5000 h
Focus	Manual
RMS rated power	2 W
Headphone outputs	2
Serial interface type	RS-232
Noise level	30 dB
Power consumption (standby)	1 W
Power consumption (typical)	235 W
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Product type	Standard throw projector
Market positioning	Presentation

Weight and Dimensions

Weight	2600 g
