ViewSonic PJD6531w User Manual

(2) Confirm LED indicator
LED Type Color Status Meaning
Power LED Blue Solid
Lamp LED Off Off
Temp LED Off Off
The projector is in standby mode.
Power LED Blue Solid
Lamp LED Off Off
Temp LED Off Off
Powering up
Power LED Blue Solid
Lamp LED Off Off
Temp LED Off Off
Normal operation
Power LED Blue Flash
Lamp LED Off Off
Temp LED Off Off
Power-down
Power LED Blue Solid(Full brightness)
Lamp LED Red Solid
Temp LED Red Flash
The projector system has some problems with its
fans, so the projector cannot start up.
Power LED Blue Solid(Full brightness)
Lamp LED Off Off
Temp LED Off Off
The lamp is in good condition and is projecting at
maximum brightness.
Power LED Blue Solid(Full brightness)
Lamp LED Off Solid
Temp LED Off Solid
The lamp has reached its end of life and must be
changed soon. The lamp will continue to operate
until it fails. Change the lamp. If the lamp is off,
then the ballast will become malfunction.
Power LED Blue Flash(Full brightness)
Lamp LED Red Solid
Temp LED Red Solid
The projector is shutting and the fan motor is
cooling the lamp for shutdown. Do not unplug the
power cord or turn the power off before the Lamp
LED changes to flashing. The fan motor will turn
off when the lamp has cooled.
Power LED Blue Solid(Full brightness)
Lamp LED Red Flash
Temp LED Red Off
Temperature is too high. The lamp will turn off.
The fan motor is cooling the lamp.
Power LED Off Off
Lamp LED Red Solid
Temp LED Red Solid
The lamp ignition failed. If temperature is too high,
the fans will cool the lamp.
Confidential - Do Not Copy
ViewSonic Corporation
PJD6531w
29

ViewSonic PJD6531w Specifications

General

Native aspect ratio	16:10
Projection distance	1.2 - 10 m
Vertical scan range	50 - 120 Hz
Horizontal scan range	31 - 80 kHz
Projection technology	DLP
Supported aspect ratios	4:3, 16:10
Contrast ratio (typical)	2000:1
Screen size compatibility	27 - 300 \
Projector native resolution	WXGA (1280x800)
Keystone correction, vertical	± 40 °
Focus	Manual
Throw ratio	1.5 - 1.8:1
Focal length range	- mm
Lamp power	230 W
Light source type	Lamp
Service life of light source	4000 h
Service life of light source (economic mode)	6000 h
Full HD	No
Supported video modes	1080i, 1080p, 480i, 480p, 576i, 576p, 720p
Analog signal format system	NTSC, PAL, SECAM
RMS rated power	10 W
Number of built-in speakers	2
Serial interface type	RS-232
USB 2.0 ports quantity	0
S-Video inputs quantity	1
VGA (D-Sub) ports quantity	3
Cables included	VGA
HDCP	-
Noise level	34 dB
Certification	CB, WEEE, UL/cUL, FCC-B, ICES-003, IRAM, NOM, PSB, C-tick, EK, CE, TUV/GS, GOST-R, Hygienic, SASO UKrSEPRO, CCC
Noise level (economic mode)	29 dB
Power source	AC
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	1 W
Power consumption (typical)	305 W
Operating temperature (T-T)	0 - 40 °C
Product color	Black
Market positioning	Presentation
Sustainability certificates	RoHS

Weight and Dimensions

Depth	114 mm
Width	280 mm
Height	218 mm
Weight	1850 g
Package depth	305 mm
Package width	345 mm
Package height	220 mm
Package weight	4500 g
