ViewSonic PJD6531w User Manual

1.3 PJD6531w Lamp Specification
Product Scope
The product is a lamp system consisting of a short arc burner within a reflector and electronic lamp
driver.
Type lamp P-VIP 230/0.8 E20.8 open type
Identcode : A 598 09C
Type driver PT VIP O3 MID(230W)-UNISHAPE
Identcode : A581 152 (lock type,Gen5,VC) or
A581 146 (lock type,Gen5,VC,DL) or
A584 924(lock type,Gen5,VC,HF)
The lamp must be operated with the OSRAM lamp driver only.
Initial Characteristics
nominal
tolerance
Input Voltage 380V DC 320…400V DC
Standby(non-operating) 120…400V DC
Max. input voltage ripple 30V
pp
@ 100-120Hz
Max. input current ripple 1Ar ms@40-300kHz
Input Wattage max.260W@230W lamp wattage
Input Wattage standby operation 1, 7W type@380V DC
Output Wattage
nominal 230W 3%
7
DIM mode 190W 3%
6
controlled by UART 190W…230W in step with of 1/128 of nominal power
Output current limitation 4.0 A(RMS) 5%
Ignition pulse typ.2.6kVpeak symm. 2.4…3.5 kVpeak
Ignition Phase Duration typ.3.5s max.6 s
Enable-Disable-Enable Cycle 15 s mi nimum
Acoustic sound pressure level typical acoustic sound pressure level 36 dB(A),maximum
38dB(A) at 25cm measuring distance; measured in ste ady
state lamp operation
8
Acoustic sound power level typical acous tic sound power level 32 dB(A) acc. to EN ISO
3744; measured in steady state lamp operation
7
Switch-off lamp voltage 140V 5V
Cooling method forced air cooling at1.5 m/s minimum
Thermal Protection Tc1 switch point 905
Safety Protections The lamp connections are not mains isolated, The lamp
can be switched on via the Start Control Input signal(SCI).
Confidential - Do Not Copy
ViewSonic Corporation
PJD6531w
9

ViewSonic PJD6531w Specifications

General

Native aspect ratio	16:10
Projection distance	1.2 - 10 m
Vertical scan range	50 - 120 Hz
Horizontal scan range	31 - 80 kHz
Projection technology	DLP
Supported aspect ratios	4:3, 16:10
Contrast ratio (typical)	2000:1
Screen size compatibility	27 - 300 \
Projector native resolution	WXGA (1280x800)
Keystone correction, vertical	± 40 °
Focus	Manual
Throw ratio	1.5 - 1.8:1
Focal length range	- mm
Lamp power	230 W
Light source type	Lamp
Service life of light source	4000 h
Service life of light source (economic mode)	6000 h
Full HD	No
Supported video modes	1080i, 1080p, 480i, 480p, 576i, 576p, 720p
Analog signal format system	NTSC, PAL, SECAM
RMS rated power	10 W
Number of built-in speakers	2
Serial interface type	RS-232
USB 2.0 ports quantity	0
S-Video inputs quantity	1
VGA (D-Sub) ports quantity	3
Cables included	VGA
HDCP	-
Noise level	34 dB
Certification	CB, WEEE, UL/cUL, FCC-B, ICES-003, IRAM, NOM, PSB, C-tick, EK, CE, TUV/GS, GOST-R, Hygienic, SASO UKrSEPRO, CCC
Noise level (economic mode)	29 dB
Power source	AC
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	1 W
Power consumption (typical)	305 W
Operating temperature (T-T)	0 - 40 °C
Product color	Black
Market positioning	Presentation
Sustainability certificates	RoHS

Weight and Dimensions

Depth	114 mm
Width	280 mm
Height	218 mm
Weight	1850 g
Package depth	305 mm
Package width	345 mm
Package height	220 mm
Package weight	4500 g
