Appendix A: RS-232 Command and Configuration
Baud Rate: 19200 Parity Bit: none
Data Bit: 8 Stop Bit: 1 Assign Port: COM1
Name Operation type CRS Header Command Response
ON BE,EF,10,05,00 C6,FF 11,11,01,00,01,00 06
Power
OFF BE,EF,03,06,00 DC,DB 69,00,00,00,00,00 06
Computer
(Analog RGB) BE,EF,03,19,00 19,29 01,47,05,CC,CC,00 06
YCbCr BE,EF,03,19,00 89,E8 01,47,05,CC,CC,00 06
S-Video BE,EF,03,19,00 E8,69 01,47,05,CC,CC,00 06
Composite
Video BE,EF,03,19,00 78,A8 01,47,05,CC,CC,00 06
Source
HDTV (Y-Pb-Pr)
BE,EF,03,19,00 DA,A8 01,47,05,CC,CC,00 06
Menu BE,EF,02,06,00 E9,D3 30,00,00,00,00,00 06
Up BE,EF,02,06,00 6D,D2 34,00,00,00,00,00 06
Down BE,EF,02,06,00 0B,D2 32,00,00,00,00,00 06
Left BE,EF,02,06,00 DA,D3 33,00,00,00,00,00 06
OSD
Right BE,EF,02,06,00 38,D2 31,00,00,00,00,00 06
On BE,EF,03,06,00 EF,DB 6A,00,00,00,00,00 06
ECO
Off BE,EF,03,06,00 3E,DA 6B,00,00,00,00,00 06
On BE,EF,03,06,00 89,DB 6C,00,00,00,00,00 06Auto
Source
Off BE,EF,03,06,00 58,DA 6D,00,00,00,00,00 06
Source BE,EF,02,06,00 57,D0 2E,00,00,00,00,00 06
Auto-Sync BE,EF,02,06,00 86,D1 2F,00,00,00,00,00 06
Blank Screen(Video) BE,EF,02,06,00 DF,DF 66,00,00,00,00,00 06
Keystone BE,EF,02,06,00 3D,DE 64,00,00,00,00,00 06
Up BE,EF,03,06,00 10,DB 65,00,00,00,00,00 06
Keystone
Down BE,EF,03,06,00 23,DB 66,00,00,00,00,00 06
Volume + BE,EF,02,06,00 F1,DE 68,00,00,00,00,00 06
Volume
Volume - BE,EF,02,06,00 20,DF 69,00,00,00,00,00 06
Image BE,EF,03,06,00 F2,DA 67,00,00,00,00,00 06
Aspect Ratio BE,EF,03,06,00 0D,DA 68,00,00,00,00,00 06
Factory Reset BE,EF,03,06,00 6B,DA 6E,00,00,00,00,00 06
Lamp Hour BE,EF,03,06,00 BA,DB 6F,00,00,00,00,00 Lamp Hour
Firware Version BE,EF,03,06,00 D5,D9 70,00,00,00,00,00 Version
