ViewSonic PJD6531w User Manual

ViewSonic Model Number: VS12476
Serial No. Prefix:RS4
Rev: 1a
Item Category Part Name Description ECR/ECN ViewSonic P/N Ref. P/N Ref. NO Compatibility Location Universal number# Remark
1 LAMP LAMP-MODULE-ASY-230W-SPARE PART_VPD-X5600_ROHS RLC-049 P4T84-2400 Main Source
2 Remote Controller REMOTE CONTROL_VIEWSONIC_02_VPD-X5400_WITHOUT/B_ROHS A-00008719 J8947-0292-02 Main Source
3 Power Cord POWER CORD (AUSTRALIA)._(SAA)YP-35/YC-12_YUNG LI_ROHS A-00008060 J2552-0053-00 Main Source
4 Power Cord POWER CORD(CHINA)._YP-03/YC-12_YUNG LI_ROHS A-00008056 J2552-0106-00 Main Source
5 Power Cord POWER CORD(EUROPE)._YP-22/YC-12_YUNG LI_ROHS A-00008057 J2552-0107-00 Main Source
6 Power Cord POWER CORD (SOUTH AFRICA)._YP-80/YC-12_YUNG LI_ROHS A-00008233 J2552-0056-01 Main Source
7 Power Cord POWER CORD(UK)._YP-61/YC-12_YUNG LI_ROHS A-00008058 J2552-0108-00 Main Source
8 Power Cord POWER CORD(USA)._UL(YP-12/YC-12)_YUNG LI_ROHS A-00008059 J2552-0109-00 Main Source
9 Power Cord POWER CORD (ARGENTINA)_SP-852+IS-14_I-SHENG_ROHS A-00008585 J2552-0263-00 Main Source
10 RS232 Cable DB9P TO DB9P CABLE_L1500_P35251A-05_PAN_ROHS CB-00009062 J2552-0208-00 Main Source
11 Signal Cable RGB to component adapter, VGA-15P-6P CABLE_P4724-08_PAN_ROHS CB-00008906 J2552-0212-00 Main Source
12 Signal Cable VGA-15P CABLE_P3842-06_PAN_ROHS CB-00008710 J2552-0072-03 Main Source
13 Soft Carrying Bag POUCH_SPARE PARTS_VPD_X5600_ROHS PJ-CASE-001 P4T84-6000 Main Source
14 Main Board MAIN_DIP_PCB_ASY_SPARE PARTS_VPD-W5600_ROHS B-00010218 P6V84-7100 Main Source
15 Power Board POWER BOARD_SPARE PARTS_VPD-X5500_ROHS B-00009752 P4S84-8100 Main Source
16 Key Pad KEYPAD_DIP_PCB_ASY_VPD-X5500_ROHS B-00009699 P4S47-7100 Main Source
17 IR Board FIR_DIP_PCB_ASY_PD-X702_ROHS (Front) B-00008158 P3747-5101 Main Source
18 IR Board BIR_DIP_PCB_ASY_P4R/VPD-X5400_ROHS (Back) B-00009700 P4R47-5101 Main Source
19 I/O Board RS232 Board, RS232_DC_DIP_PCB_ASY_VPD-X5500_ROHS B-00009750 P4S47-6101 Main Source
20 Ballast OSRAM-BALLAST-230W-SPARE PART_VPD-X5600_ROHS B-00009753 P4T84-9000 Main Source
21 DMD Board DMD450_DIP_PCB_ASY_TPD-S5500_ROHS B-00009703 P4D47-6100 Main Source
22 Sensor Board CW SENSOR_DIP_PCB_ASY_IPD-S5530_ROHS B-00009837 P5E47-5100 Main Source
23 Lamp Cover LAMP COVER_SPARE PARTS_VPD-X5400_ROHS C-00009630 P4R84-4520 Main Source
24 Top Cover TOP COVER_SPARE PARTS_VPD-W5600_ROHS C-00010149 P6V84-4500 Main Source
25 Bottom Cover BOTTOM COVER_SPARE PARTS_VDP-X5400_ROHS C-00009632 P4R84-4510 Main Source
26 IO Cover I/O COVER_SPARE PARTS_VPD-X5700_ROHS C-00009786 P5B84-4530 Main Source
27 Filter Cover FILTER COVER_VPD-X5400_00_NO PAINTING_ROHS C-00009635 P4R34-4600-00 Main Source
28 Lens Cover LENS CAP_TPD-X5500_00_NO PAINTING_ROHS C-00009638 P4E34-4650-00 Main Source
29 Wire FFC CABLE_A20240C3344NB_ENTERY_0.5PITCH_20PIN_L240MM_ROHS(top cover to main board) CB-00009052 J2591-0122-00 Main Source
30 Wire WIRE CON-CON_1102003-236_MSK_4PIN_L105MM_1571#28_ROHS(color wheel to main board) CB-00009158 J2595-0368-01 Main Source
31 Wire WIRE CON-CON_1102003-231_MSK_10PIN-2*8PIN_L115MM_1007#24_ROHS(power board to main board) CB-00009054 J2595-0407-00 Main Source
32 Wire WIRE CON-CON_1102003-98_MSK_2PIN_L140MM_1015#22_ROHS(power board to ballast) CB-00008469 J2595-0218-00 Main Source
33 Wire WIRE ASSY_CON-SW_1102003-202_MSK_ROHS(top cover to main board) CB-00009055 J2595-0366-00 Main Source
34 Wire WIRE CON-CON_1102003-203_MSK_4PIN_L115MM_1571#28_ROHS(IR to main board) CB-00009056 J2595-0367-00 Main Source
35 Wire WIRE LAMP-BALA(VPD-X5400)_01800182R_AVERTRONICS_2PIN_L135MM_3239V#20_ROHS(Ballast to Lamp) CB-00009097 J2595-0363-00 Main Source
36 Wire
WIRE CON-MOTOR PROTECTOR_2PIN_L65MM_1332#24_ROHS(? 控??)
CB-00009058 J2595-0346-00 Main Source
37 Wire WIRE CON-CON_1102003-235_MSK_3PIN_L185MM_1571#28_ROHS(RS232 Board to main board) CB-00009156 J2595-0371-01 Main Source
38 Wire WIRE CON-CON_1102003-206_MSK_5PIN_L95MM_1571#28_ROHS(Ballast to main board) CB-00009060 J2595-0370-00 Main Source
39 Wire WIRE CON-CON_1102003-205_MSK_4PIN_L130MM_1571#28_ROHS(power board to RS232 board) CB-00009061 J2595-0369-00 Main Source
40 Wire WIRE CON-CON_1102003-234_MSK_5PIN_L120MM_1571#28_ROHS(RS232 Board to main board) CB-00009094 J2595-0410-00 Main Source
41 Qucik Start Guide (QSG) QG_VIEWSONIC_VPD-W5600_GLOBAL_ROHS DC-00010294 P6V39-4000-00 Main Source
42 CD ROM CD ROM_VIEWSONIC_VPD-X5400_AP CD_ROHS(for LAN Software) DC-00009956 P4R39-A001-01 Main Source
43 User's Guide (CD ROM) CD ROM_VIEWSONIC_VPD- W5600_GLOBAL_ROHS DC-00010295 P6V39-A000-00 Main Source
44 Label / Sticker C/T LB_NO BRAND_GLOBAL_ROHS(for Taiwan) DC-00008794 J4238-5069-00 Main Source
45 Label / Sticker CARTON LB_VIEW SONIC_PJ557D_GLOBAL_ROHS(for China) DC-00008672 P0N38-5013-00 Main Source
46 Optical Engine OPTICAL ENGINE ASY(WITHOUT LAMP)SPARE PARTS_VPD-W5600_ROHS E-00010054 P6V84-2200 Main Source
47 Color Wheel COLOR-WHEEL MODULE_SPARE PARTS_VPD-W5600_ROHS E-00010055 P6V84-2600 Main Source
48 Lens LENS ASY_SPARE PARTS_VPD-W5600_ROHS E-00010056 P6V84-6500 Main Source
49 Speaker SPEAKER_P40KCG08-3-7JS1_SPARE PARTS_FRONT_VPD-X5600_ROHS E-00009557 P4T84-0001 Main Source
50 Speaker SPEAKER_P40KCG08-3-7JS1_SPARE PARTS_BACK_VPD-X5600_ROHS E-00009558 P4T84-0002 Main Source
51 Screw HEXAGON-HEAT-BOLT-4_MPD-S651_3M_ROHS HW-00008066 82035-2520-00 Main Source
52 Metal Frame METAL DOME P4R_VPD-X5400_ROHS HW-00008927 P4R38-1510-00 Main Source
Keypad film,sticking on
the keypad board
53 Screw SCREW_TP_3_10_A_2_D=5.5_BLACK_NONE_ROHS HW-00008860 J1635-3670-00 Main Source
54 Screw SCREW_M_3_8.0_E_1.5_D=5.0_BLACK_NL_ROHS HW-00008861 J1635-C072-00 Main Source
55 Screw SCREW-WASHER_TP_2_4_D_1_D=3.2_NI_NONE_SUS_ROHS HW-00008043 J1635-3720-00 Main Source
56 Screw SCREW_M_2_5_A_D=3_A0.8_BLACK_HEAT-TREATMENT_ROHS HW-00008862 J1635-2250-00 Main Source
57 Screw SCREW-WASHER_M_4_6_A_2.6_D=7_ZN_NONE_SUS_ROHS HW-00008863 J1635-D420-0A Main Source
58 Screw SCREW-WASHER_TP_3_6_D_2.6_D=5.4_ZN_NONE_SUS_ROHS HW-00008864 J1635-3620-0A Main Source
59 Screw SCREW-WASHER._TP_3_10_D_7_D=5.3_NI_NONE_SUS_ROHS HW-00008345 J1635-A491-00 Main Source
60 Screw SCREW+WASHER_M_3_6_D_2_D=5.3_ZN_NONE_SUS_ROHS HW-00008865 J1635-B853-0A Main Source
61 Screw SCREW_TP_1.8_3_E_0.3_D=4.5_BLACK_NONE_ROHS HW-00008866 J1635-D559-00 Main Source
62 Screw SCREW_TP_2_10_A_1.2_D=3.5_NI_NONE_ROHS HW-00008867 J1635-3494-00 Main Source
63 Fan FAN_3110RL-04W-S59-F00(L=60MM)_NMB_ROHS M-00008212 J2394-0101-00 Main Source
64 Fan FAN_3110RL-04W-S59-F03(L=60MM)_NMB_ROHS M-00008342 J2394-0101-01 Main Source
65 Fan FAN_BFB0512VHD-8L07(L=65MM)_DELTA_ROHS M-00008343 J2394-0117-00 Main Source
66 Ring FOCUS RING, RINGS-SPARE PARTS_VPD-W5600_ROHS M-00008577 P6V84-4540 Main Source
67 Ring ZOOM RING TOP_VPD-W5600_99_FOR PAINTING_ROHS M-00008578 P6V34-4550-99 Main Source
68 SPONGE FILTER SPONGE_2 P4R_VPD-X5400_ROHS M-00008381 P4R38-1590-00 Main Source
69 FILTER SPONGE FILTER SPONGE P4R_VPD-X5400_ROHS M-00008382 P4R38-1580-00 Main Source
70 PAD FAN PAD_TPD-X5500_ROHS M-00008390 P4E38-1070-00 Main Source
71 Pad PAD_PREMIER_PD-S650_GLOBAL_ROHS M-00008389 P8339-6900-00 Main Source
72 SPONGE FAN SPONGE P4R_VPD-X5400_ROHS M-00008393 P4R38-1530-00 Main Source
73 Rubber Foot FOOT-REAR_TPD-X5500_ROHS M-00008344 P4E38-1570-00 Main Source
74 Carton CARTON_VIEWSONIC_VPD-W5600_GLOBAL_ROHS P-00010191 P6V39-6000-00 Main Source
75 Foam EPE_NO_VPD-X5400_FOR BODY_ROHS P-00009685 P4R39-7000-00 Main Source
76 Plastic Bag PE BAG._NO BRAND_298MM*190MM_ROHS P-00008794 J4039-R184-01 Main Source
77 Plastic Bag PE BAG._NO BRAND_GLOBAL_ROHS P-00008410 J4039-R157-01 Main Source
78
Plastics: [Pedestal, Plate,
Button, etc.]
Housing LENS HOUSING_VPD-X5400_00_NO PAINTING_ROHS PL-00008833 P4R34-4570-00 Main Source
Remark 1:
Above listed items are examples, supplier can expand the rows to add more necessary items.
Remark 2:
Notice: 1. For some special parts, some photos for identification purpose may be asked by request
2. For all internal cables, there must be some wordings on the "Description" column about where the cable is used (connecting to which two parts)
3. All internal cables/wires should be put in the "Cables" category
4. All external cables should be put in the "Accessories" category
5. Parts relationship (Main/Second source or 1/2/3/4) should be added in the "Compatibility" column
6. If any part for certain product isn't listed in the form, supplier/PE can add it themselves and keep the part name unified.
All revised RSPLs with newly added items or any change made should be highlighted and correlated with the ECN/ECR approved by ViewSonic Corporation. This is to eliminate repeated cross checks of each item between this version and prior versions.
Cabinets: [Front Bezel,
All Covers, Base
Assembly]
Miscellaneous: [Switch,
Fan, Rubber Foot, Logo]
Documentation: [Quick
Start Guide, CD Rom;
Label]
Packing Material: [Box,
Foam, Bags]
Cables: [All internal
Cables/wires]
Electronic Components:
[Optical Engine, Speaker,
Color Wheel]
RECOMMENDED SPARE PARTS LIST (PJD6531w)
Hardware: [Screw,
Bracket, Hinge]
PC Board Assembly: [All
PCBA]
Accessories: [Adapter,
Remote Controller,
Power Cord, External
Cables]
Confidential - Do Not Copy
ViewSonic Corporation
PJD6531w
9 Recommended Spare Parts List
65

ViewSonic PJD6531w Specifications

General

Native aspect ratio	16:10
Projection distance	1.2 - 10 m
Vertical scan range	50 - 120 Hz
Horizontal scan range	31 - 80 kHz
Projection technology	DLP
Supported aspect ratios	4:3, 16:10
Contrast ratio (typical)	2000:1
Screen size compatibility	27 - 300 \
Projector native resolution	WXGA (1280x800)
Keystone correction, vertical	± 40 °
Focus	Manual
Throw ratio	1.5 - 1.8:1
Focal length range	- mm
Lamp power	230 W
Light source type	Lamp
Service life of light source	4000 h
Service life of light source (economic mode)	6000 h
Full HD	No
Supported video modes	1080i, 1080p, 480i, 480p, 576i, 576p, 720p
Analog signal format system	NTSC, PAL, SECAM
RMS rated power	10 W
Number of built-in speakers	2
Serial interface type	RS-232
USB 2.0 ports quantity	0
S-Video inputs quantity	1
VGA (D-Sub) ports quantity	3
Cables included	VGA
HDCP	-
Noise level	34 dB
Certification	CB, WEEE, UL/cUL, FCC-B, ICES-003, IRAM, NOM, PSB, C-tick, EK, CE, TUV/GS, GOST-R, Hygienic, SASO UKrSEPRO, CCC
Noise level (economic mode)	29 dB
Power source	AC
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	1 W
Power consumption (typical)	305 W
Operating temperature (T-T)	0 - 40 °C
Product color	Black
Market positioning	Presentation
Sustainability certificates	RoHS

Weight and Dimensions

Depth	114 mm
Width	280 mm
Height	218 mm
Weight	1850 g
Package depth	305 mm
Package width	345 mm
Package height	220 mm
Package weight	4500 g
