ViewSonic PJD6531w User Manual

I/O port USB
Test Equipment
PC and Remote controller
Test method
1. Connect PC (laptop) VGA output to projector.
Set PC (laptop) output signal to projector
2. Connect projector USB to PC.
Press remote controller page up/down to scroll presentation file up and
down (ex Microsoft office series)
I/O port Audio input
Test Equipment
Connect audio input to audio output of DVD player
Signal format
480i
I/O port HDMI
Test Equipment
HDMI source device
Signal format
480p
(3) Operation test
Buttons operation
Button description Test criteria
Power button
1. Mechanical motion (Up & Down) should be free from getting stuck
when pressing the button
2. Press “power” button and projector will switch on
Menu
1. Mechanical motion (Up & Down) should be free from gettin g stuck
when pressing the button.
2. Press Menu button can make projector function normally.
4-way button
1. Mechanical motion (Up & Down) should be free from getting stuck
when pressing the 4-way button.
2. Press 4-way button can be used to scroll through OSD (On-
Screen Display) menus and make adjustments.
Source
1. Mechanical motion (Up & Down) should be free from getting stuck
when pressing the button
2. Press Source button manually selects an input source
Foot adjuster operation
Foot adjuster. Test criteria
Foot adjuster button
Foot adjusters should stretch downward smoothly by pressing the foot
adjuster buttons on the two sides
Confidential - Do Not Copy
ViewSonic Corporation
PJD6531w
37

ViewSonic PJD6531w Specifications

General

Native aspect ratio	16:10
Projection distance	1.2 - 10 m
Vertical scan range	50 - 120 Hz
Horizontal scan range	31 - 80 kHz
Projection technology	DLP
Supported aspect ratios	4:3, 16:10
Contrast ratio (typical)	2000:1
Screen size compatibility	27 - 300 \
Projector native resolution	WXGA (1280x800)
Keystone correction, vertical	± 40 °
Focus	Manual
Throw ratio	1.5 - 1.8:1
Focal length range	- mm
Lamp power	230 W
Light source type	Lamp
Service life of light source	4000 h
Service life of light source (economic mode)	6000 h
Full HD	No
Supported video modes	1080i, 1080p, 480i, 480p, 576i, 576p, 720p
Analog signal format system	NTSC, PAL, SECAM
RMS rated power	10 W
Number of built-in speakers	2
Serial interface type	RS-232
USB 2.0 ports quantity	0
S-Video inputs quantity	1
VGA (D-Sub) ports quantity	3
Cables included	VGA
HDCP	-
Noise level	34 dB
Certification	CB, WEEE, UL/cUL, FCC-B, ICES-003, IRAM, NOM, PSB, C-tick, EK, CE, TUV/GS, GOST-R, Hygienic, SASO UKrSEPRO, CCC
Noise level (economic mode)	29 dB
Power source	AC
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	1 W
Power consumption (typical)	305 W
Operating temperature (T-T)	0 - 40 °C
Product color	Black
Market positioning	Presentation
Sustainability certificates	RoHS

Weight and Dimensions

Depth	114 mm
Width	280 mm
Height	218 mm
Weight	1850 g
Package depth	305 mm
Package width	345 mm
Package height	220 mm
Package weight	4500 g
