ViewSonic PJD6531w User Manual

Item
ViewSonic P/N
Ref. P/N
Description
Q'ty
1
C-00010149
P6V84-4500
Top Cover
1
2 C-00009638 P4E34-4650-00 Lens Cover 1
3 n/a P4T84-4530 IO Cover 1
4 C-00009630 P4R84-4520 Lamp Cover 1
5 C-00009635 P4R34-4600-00 Filter Cover 1
6
PL-00008833
P4R34-4570-00 Lens Housing 1
7 RLC-049 P4T84-2400 Lamp Module 1
8
E-00010054
P6V84-2200 Optical Engine 1
9
B-00010218
P6V84-7100
Main Board
1
10 B-00009750 P4S47-6101 RS232 Board 1
11 B-00009703 P4D47-6100 DMD Board 1
12 B-00008158 P3747-5101 FIR Board 1
13 B-00009700 P4R47-5101 BIR Board 1
14 B-00009753 P4T84-9000 Ballast 1
15 E-00009557 P4T84-0001 Front Speaker 1
16 E-00009558 P4T84-0002 Back Speaker 1
17 M-00008342 J2394-0101-01 Fan2 1
18 M-00008212 J2394-0101-00 Fan1 1
19 B-00009752 P4S84-8100 Power Board 1
20 C-00009632 P4R84-4510 Bottom Cover 1
21 M-00008344 P4E38-1570-00 Rear Foot 1
EXPLODED PARTS LIST (PJD6531w)
ViewSonic Model Number: VS12476
Rev: 1a
Confidential - Do Not Copy
ViewSonic Corporation
PJD6531w
47

ViewSonic PJD6531w Specifications

General

Native aspect ratio	16:10
Projection distance	1.2 - 10 m
Vertical scan range	50 - 120 Hz
Horizontal scan range	31 - 80 kHz
Projection technology	DLP
Supported aspect ratios	4:3, 16:10
Contrast ratio (typical)	2000:1
Screen size compatibility	27 - 300 \
Projector native resolution	WXGA (1280x800)
Keystone correction, vertical	± 40 °
Focus	Manual
Throw ratio	1.5 - 1.8:1
Focal length range	- mm
Lamp power	230 W
Light source type	Lamp
Service life of light source	4000 h
Service life of light source (economic mode)	6000 h
Full HD	No
Supported video modes	1080i, 1080p, 480i, 480p, 576i, 576p, 720p
Analog signal format system	NTSC, PAL, SECAM
RMS rated power	10 W
Number of built-in speakers	2
Serial interface type	RS-232
USB 2.0 ports quantity	0
S-Video inputs quantity	1
VGA (D-Sub) ports quantity	3
Cables included	VGA
HDCP	-
Noise level	34 dB
Certification	CB, WEEE, UL/cUL, FCC-B, ICES-003, IRAM, NOM, PSB, C-tick, EK, CE, TUV/GS, GOST-R, Hygienic, SASO UKrSEPRO, CCC
Noise level (economic mode)	29 dB
Power source	AC
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	1 W
Power consumption (typical)	305 W
Operating temperature (T-T)	0 - 40 °C
Product color	Black
Market positioning	Presentation
Sustainability certificates	RoHS

Weight and Dimensions

Depth	114 mm
Width	280 mm
Height	218 mm
Weight	1850 g
Package depth	305 mm
Package width	345 mm
Package height	220 mm
Package weight	4500 g
