ViewSonic VS18454 - LAN Hardware Specification; RS-232 Communication Setting; LAN Communication Setting; Command Message Reference

95
LAN Hardware Specicaon

1. Connector type: 8P8C RJ45
2. Pin Assignment:
Pin # Signal Remark
1  Output from Display
2 TX- Output from Display
3  Input to Display
4  For 1G case
5 BI_D3- For 1G case
6 RX- Input to Display
7  For 1G case
8 BI_D4- For 1G case
frame GND
RS-232 Communicaon Seng
- Baud Rate Select: 
- Data bits: 
- Parity: 
- Stop Bits: 
LAN Communicaon Seng
- Type: Ethernet
- Protocol: TCP/IP
- Port: 
- WOL Port: *3.2.0
- Cross subnet: No
 No
Command Message Reference

command to Display, the Display shall respond as follows:
1. 
(00Dh)
2. If the message is received incorrectly it will send “-” (02Dh) followed by “CR”
(00Dh)
