Diagnostics
Service Tests (continued)
165 Dispenser Lamp
This test shows the state of the dispenser lamp (On or OFF).
Note: By pushing actuator pad or express fill keypad you can control state of dispenser lamp.
168 Cube Dispenser and Internal Ice Chute Door Operation
This test shows the state of the ice auger motor and the internal ice chute door
(On or OFF).
Note: By pushing actuator pad you can control state of the ice auger motor and the internal ice chute door.
171 Actuator Pad
Display shows the state of the actuator pad (On or OFF).
Press either
button to
toggle through
test cycles
165 OFF
Press either
button to
toggle through
test cycles
Press either
button to
toggle through
test cycles
171 OFF
