Freezer Drawer Switch
To access the freezer drawer switch:
1. Open drawer.
2. Use a flat blade to depress light switch securing
tabs.
3. Pull switch into freezer compartment and
disconnect wiring.
4. Repair or replace switch.
5. Reverse procedure to reinstall.
Freezer Light Bulb
The unit uses a standard 40W, 120VAC light bulb to
illuminate the freezer compartment.
To access the light bulb:
1. Open freezer drawer to replace light bulb.
Freezer Light Housing
To access light housing:
1. Remove freezer light bulb (see freezer light
bulbs section above).
2. Press tabs securing light housing.
WARNING
To avoid risk of electrical shock, personal injury, or death, disconnect electrical power to unit using power
switch before servicing. Wires removed during disassembly must be replaced on proper terminals to insure
correct earth ground and polarization. After servicing, reconnect power using power switch.
Service Diagnostics and Procedures–Disassembly
Tabs
Screwdriver
