7509 - 7509/D Tab
EN
ID code configuration
The ID code is congured by means of a main (MASTER) outdoor station, already congured and present in the
system.
The entryphone is supplied without an associated identication code. To verify this, press the lock release button and
the entryphone should emit an audible signal (three beeps).
Caution: when conguring the indoor station identication code, you only have 30 seconds from the moment
you enter indoor station conguration mode in which to press the call button on the entrance panel or to
send the code.
Conguration procedure (“Simplied” mode):
Raise the handset and bring it to your ear to listen to the sound feedback emitted by the entryphone during
the conguration phase.
1. Press and hold down the lock release button “
” for 6 s. When the time runs out the indoor station will emit a
“beep” (0.5 s).
2. Release the lock release button “
”. When the button is released the communication will be signalled by a “beep”
with a di󰀨erent frequency.
3. Press the button on the MASTER outdoor station you wish to receive the call from. (*)
4. The ID code is associated with the indoor station and communication is ended. An acoustic signal conrms the
operation was successful. (**)
beep
BEEP
BEEP
beep
1
> 6 s
*
2 3
**
4
beep
BEEP
BEEP
beep
1
> 6 s
*
2 3
**
4
