Manual VIPA System 300S SPEED7 Chapter 5 Deployment I/O periphery
HB140E - CPU SC - RE_313-6CF03 - Rev. 07/45 5-17
Continuous count:
Job Valid range
Writing counter directly -2147483647 (-2
31
+1) to +2147483646 (2
31
-2)
Writing the load value -2147483647 (-2
31
+1) to +2147483646 (2
31
-2)
Writing comparison value -2147483648 (-2
31
) to +2147483647 (2
31
-1)
Writing hysteresis 0 to 255
Writing pulse duration* 0 to 510ms
Single/periodic count, no main count direction:
Job Valid range
Writing counter directly -2147483647 (-2
31
+1) to +2147483646 (2
31
-2)
Writing the load value -2147483647 (-2
31
+1) to +2147483646 (2
31
-2)
Writing comparison value -2147483648 (-2
31
) to +2147483647 (2
31
-1)
Writing hysteresis 0 to 255
Writing pulse duration* 0 to 510ms
Single/periodic count, main count direction up:
Job Valid range
End value 2 to +2147483646 (2
31
-1)
Writing counter directly -2147483648 (-2
31
) to end value -2
Writing the load value -2147483648 (-2
31
) to end value -2
Writing comparison value -2147483648 (-2
31
) to end value -1
Writing hysteresis 0 to 255
Writing pulse duration* 0 to 510ms
Single/periodic count, main count direction down:
Job Valid range
Writing counter directly 2 to +2147483647 (2
31
-1)
Writing the load value 2 to +2147483647 (2
31
-1)
Writing comparison value 1 to +2147483647 (2
31
-1)
Writing hysteresis 0 to 255
Writing pulse duration* 0 to 510ms
*) Only even values allowed. Odd values are automatically rounded.
As soon as during a count process an edge 0-1 is recognized at the
"Latch" input of a counter, the recent counter value is stored in the
according latch register.
You may access the latch register via LATCHVAL of the SFB 47.
A just in LATCHVAL loaded value remains after a STOP-RUN transition.
Permitted value
range for
JOB_VAL
Latch function
