VIPA System 300S SPEED7 CPU 313SC/DPM User Manual

Manual VIPA System 300S SPEED7 Chapter 3 Hardware description
HB140E - CPU SC - RE_313-6CF03 - Rev. 07/45 3-9
Technical Data
Module name 313-6CF03
Dimensions and weight
Dimensions W x H x D 80 x 125 x 120mm
Weight 420g
Voltages, Currents, Potentials
Power supply (rated value) DC 24V
- Permitted range 20.4 ... 28.8V
- Reverse polarity protection yes
Current consumption (no-load operation) 200mA
Inrush current typ. 11A
Power consumption (nominal value) 900mA
I
2
t 0.7A
2
s
External fusing of power supply lines
(recommended)
2A
Power loss 14W
Accumulator Lithium
- Clock back-up period 30 days
Memory
Work memory
- integrated 64kByte
- expandable up to 512kByte
Processing times
Processing times for
- Bit instructions 0.021µs
- Word instructions 0.021µs
- Double integer arithmetic 0.021µs
- Floating-point arithmetic 0.125µs
Timers/Counters and their retentive characteristics
S7 counters 512
- Retentivity adjustable
- Preset up C0 to C7
- Count value 0 up to 999
IEC counters yes
- Type SFB
- Number unlimited (limited only by RAM size)
S7 timers 512
- Retentivity adjustable
- Preset not retentive
- Time value 10ms up to 9990s
ICE timers yes
- Type SFB
- Number unlimited (limited only by RAM size)
Data areas and their retentive characteristics
Bit memories 8192Byte
- Adjustable retentivity adjustable
- Preset up MB0 to MB15
Clock memories 8 (1 flag byte)
Data blocks max. 4095
- Size 64kByte
Local data
- per priority class 510Byte
continued ...
