VIPA System 300S SPEED7 CPU 313SC/DPM User Manual

Chapter 4 Deployment CPU 313SC/DPM Manual VIPA System 300S SPEED7
4-14 HB140E - CPU SC - RE_313-6CF03 - Rev. 07/45
CPU parameterization
Since the CPU 313SC/DPM of VIPA is to be configured as Siemens CPU
313C-2DP in the Siemens hardware configurator, the parameters of the
CPU 313SC/DPM may be set with "Object properties" during hardware
configuration.
Via a double-click on the CPU 313C-2DP the parameter window may be
accessed.
Using the registers you get access to all parameters of the CPU.
Note!
A description of the parameters of the sub module DI16/DO16 and Count
may be found at chapter "Deployment I/O periphery".
