Manual VIPA System 300S SPEED7 Chapter 2 Assembly and installation guidelines
HB140E - CPU SC - RE_313-6CF03 - Rev. 07/45 2-3
Installation dimensions
2tier width (WxHxD) in mm: 80 x 125 x 120
65mm
40mm
122mm
125 mm
125mm
120mm
175mm
Dimensions Basic
enclosure
Dimensions
Installation
dimensions
