Manual VIPA System 300S SPEED7 Chapter 4 Deployment CPU 313SC/DPM
HB140E - CPU SC - RE_313-6CF03 - Rev. 07/45 4-21
Parameterization of modules
By using the SIMATIC Manager from Siemens you may set parameters for
configurable System 300 modules at any time.
For this, double-click during the project engineering at the slot overview on
the module you want to parameterize In the appearing dialog window you
may set the wanted parameters.
By using the SFCs 55, 56 and 57 you may alter and transfer parameters
for wanted modules during runtime.
For this you have to store the module specific parameters in so called
"record sets".
More detailed information about the structure of the record sets is to find in
the according module description.
Approach
Parameterization
during runtime
