Manual VIPA System 300S SPEED7 Chapter 5 Deployment I/O periphery
HB140E - CPU SC - RE_313-6CF03 - Rev. 07/45 5-5
Address assignment
Sub module Default
address
Access Assignment
DI16/DO16 124 Byte Digital Input I+0.0 ... I+0.7
125 Byte Digital Input I+1.0 ... I+1.7
Counter 768 DInt Channel 0: Count value / Frequency value
772 DInt Channel 1: Count value / Frequency value
776 DInt Channel 2: Count value / Frequency value
780 DInt reserved
Sub module Default
address
Access Assignment
DI16/DO16 124 Byte Digital Output Q+0.0 ... Q+0.7
125 Byte Digital Output Q+1.0 ... Q+1.7
Counter 768 DWord reserved
772 DWord reserved
776 DWord reserved
780 DWord reserved
Input range
Output range
