The parity is -depending on the value- even or odd. For parity control, the
information bits are extended with the parity bit, that amends via its value
("0" or "1") the value of all bits to a defined status. If no parity is set, the
parity bit is set to "1", but not evaluated.
0: NONE 1: ODD 2: EVEN
The stop bits are set at the end of each transferred character and mark the
end of a character.
1: 1Bit 2: 1.5Bit 3: 2Bit
The parameter FlowControl is ignored. When sending RST=0, when
receiving RST=1.
Return values send by the block:
Error code Description
0000h no error
809Ah interface not found
8x24h Error at SFC-Parameter x, with x:
1: Error at "Protocol"
2: Error at "Parameter"
3: Error at "Baudrate"
4: Error at "CharLength"
5: Error at "Parity"
6: Error at "StopBits"
7: Error at "FlowControl" (Parameter missing)
809xh Error in SFC parameter value x, where x:
1: Error at "Protocol"
3: Error at "Baudrate"
4: Error at "CharLength"
5: Error at "Parity"
6: Error at "StopBits"
7: Error at "FlowControl"
8092h Access error in parameter DB (DB too short)
828xh Error in parameter x of DB parameter, where x:
1: Error 1. parameter
2: Error 2. parameter
...
Parity
StopBits
FlowControl
RetVal SFC 216
(Error message
SER_CFG)
