Manual VIPA System 300S SPEED7 Chapter 6 Deployment PtP communication
HB140E - CPU SC - RE_313-6CF03 - Rev. 07/45 6-13
Return values of the block:
Error code Description
0000h Send data - ready
1000h Nothing sent (data length 0)
20xxh Protocol executed error free with xx bit pattern for
diagnosis
7001h Data is stored in internal buffer - active (busy)
7002h Transfer - active
80xxh Protocol executed with errors with xx bit pattern for
diagnosis (no acknowledgement by partner)
90xxh Protocol not executed with xx bit pattern for diagnosis (no
acknowledgement by partner)
8x24h Error in SFC parameter x, where x:
1: Error in "DataPtr"
2: Error in "DataLen"
8122h Error in parameter "DataPtr" (e.g. DB too short)
807Fh Internal error
809Ah Interface not found or interface is used for Profibus
809Bh Interface not configured
ASCII
Value Description
9000h Buffer overflow (no data send)
9002h Data too short (0Byte)
STX/ETX
Value Description
9000h Buffer overflow (no data send)
9001h Data too long (>1024Byte)
9002h Data too short (0Byte)
9004h Character not allowed
3964R
Value Description
2000h Send ready without error
80FFh NAK received - error in communication
80FEh Data transfer without acknowledgement of partner or error
at acknowledgement
9000h Buffer overflow (no data send)
9001h Data too long (>1024Byte)
9002h Data too short (0Byte)
RetVal SFC 217
(Error message
SER_SND)
Protocol specific
RetVal values
