Chapter 1 Basics Manual VIPA System 300S SPEED7
1-8 HB140E - CPU SC - RE_313-6CF03 - Rev. 07/45
• Operating temperature: 0 ... +60°C
• Storage temperature: -25 ... +70°C
• Relative humidity: 5 ... 95% without condensation
• Ventilation by means of a fan is not required
• Dimensions of the basic enclosure: 2tier width: (HxWxD) in mm:
80x125x120
• Available lengths of the profile rail in mm: 160, 482, 530, 830 and 2000
Modules and CPUs of the System 300 from VIPA and Siemens may be
used at the "Standard" bus as a mixed configuration.
The project engineering takes place in WinPLC7 from VIPA or in the
hardware configurator from Siemens.
The SPEED7 CPUs from VIPA are instruction compatible to the
programming language STEP
®
7 from Siemens and may be programmed
via WinPLC7 from VIPA or via the Siemens SIMATIC Manager.
Here the instruction set of the S7-400 from Siemens is used.
Note!
Please do always use the CPU 313C-2DP (6ES7 313-6CF03-0AB0 V2.0)
from Siemens of the hardware catalog to project a CPU 313SC/DPM from
VIPA.
For the project engineering, a thorough knowledge of the Siemens
SIMATIC Manager and the hardware configurator from Siemens is
required!
The CPU comes with an integrated power supply. The power supply has to
be supplied with DC 24V. By means of the supply voltage, the bus coupler
electronic is supplied as well as the connected modules via backplane bus.
The power supply is protected against inverse polarity and overcurrent.
Environmental
conditions
Dimensions/
Weight
Compatibility
Integrated
power supply
