Transfer CP project
In the "network" window mark the station to be transfered.
• Activate the online functions via
.
• If there is still an online connection to the CP, set the CP into software
STOP via
an start transfer with .
Otherwise set "IP protocol" under
and type the IP address
172.16.192.11 (delivery address).
• Establish a connection via
.
• Set the CP into software STOP via
.
• With
, the transfer into the CP starts. If a request for a NCS file
appears, you forgot to choose the "CPU 31xNET" in the network
window! Return to the last step, choose the correct setting and start the
transfer again.
• As soon as the transfer has finished, reboot the CP via
.
Now the CP is on the network with the assigned IP address.
