USER MANUAL
11
connector to the middle section of the rear part.
7. Check if the receiving surface of the sealing strip (G) is intact and seals adequately.
8. Close recovery tank lid (A).
Figure 11
SOLUTION FILTER CLEANING
1. Drain all the water from Solution tank as previously outlined.
2. Move the machine to a flat and smooth surface.
3. Press the power switch (38) to the “O” position to turn off the machine.
4. Turn off the draining ball valve (A, Figure 12) (located at the bottom of the machine, behind the
wheels). Position B ball valve open, and position C ball valve closed.
5. Remove the transparent cap (D), and then take off the filter (E), and install them onto the filter
box (F) after cleaning.
NOTE
The filter (E) must be accurately installed onto the position of the housing (G).
6. Open the draining ball valve (A).
Figure 12
Filter Mesh Mark
