USER MANUAL
3
-
This machine must be only used by trained & authorized personnel. Children or untrained persons
must not use this machine.
-
When working near electrical parts, please do not wear any jewelry. Please take all precautionary
measures to avoid hair, jewelry, and loose fitting clothing from being caught by any moving parts of
the machine.
-
Prior to scrubbing, it is best to pre-sweep the area to be cleaned. Do not wash the machine directly
with water. Do not let the machine come in touch with corrosive liquids.
-
The temperature for storage and for working environment of the machine must be between 0 - 40
0
C.
-
The humidity of air must be between 30% - 105%.
-
Please do not use the machine on a slope with a gradient of more than 2%.
-
In case of fire, please use dry powder fire extinguishers. Do not use liquid fire extinguishers.
-
Particular attention should be paid when the machine is transported below 0
0
C. The water tank and
the water in the hoses may freeze and cause serious damages to the machine.
-
Use brush or pad driver supplied with the machine and those specified in the owners manual. Using
other brushes or pads could reduce safety.
-
In case of machine malfunction, please make sure that it is not caused by lack of maintenance. If it is
caused by other conditions, contact your local Viper authorized service center. If it is confirmed that
spare parts must be replaced, please secure the genuine parts from your local Viper distributor.
-
In order to ensure safe and proper operation of the machine, it is advised that your Viper authorized
service provider perform the scheduled maintenance according to the maintenance schedules
outlined in this manual.
-
This machine must be properly disposed of in accordance with local laws and regulations (please
refer to machine disposal section).
TECHNICAL DATA
Model AS430C
Machine Height 980mm
Solution tank capacity 50 litre
Recovery tank capacity 50 litre
Diameter of transport wheel 200mm
Diameter of guide wheel 63.5mm
Power of vacuum system motor 400w
Maximum gradient when working
2
％
(Max)
Sound pressure level at workstation
72dB(A
）
±3dB(A)
Cable length 20m
Vacuum system circuit capacity
1200 mm H
2
O
Cleaning width
430mm
Squeegee width
730mm
machine maximum length
1060mm
Machine width without squeegee
480mm
Brush diameter
430mm
Weight with empty tanks
70kg
Gross weight of the machine ready for use
120kg
Brush motor power
750W
Brush speed
150rpm
Brush /pad-holder Maximum pressure
32kg (Max)
Packing size (Lx W x H)
1200 x 610 x 1170mm
