Viper AS430C User Manual

Item Part No. Description Qty
TANK SYSTEM
AS430C PART LIST
37 VF13604 GROOVED METAL GASKET 1
38 VF90235 SCEREW TM4x10 1
39 VF90508 SUCTION HOSE 2
40 VF90231 GASKET 1
41 VF90214 SEAL PLATE COVER 2
42 VF90217 SEAL PLATE 2
43 VA80758 SCREW 4
44 VF90529 SUCTION TUBE CONNECTER 1
45 VF90528 DRAIN HOSE CONNECTOR 1
46 VF90512 SUCTION TUBE GASKET 2
47 VF90509 SEALING KNOB 2
48 VA20304 CLAMP 4
49 VF90534 FLOAT KIT 1
50 VF90530 CAGE,FLOAT COMPLETE 1
51 VF90526 FLOAT BRACKET 1
52 VF85124 FLOATE 1
53 VF90527 FLOATE BRACKET COVER 1
54 VF90218 CONTROL SEAL GASKET 1
55 VF90401 DRAIN HOSE CONNECTER 1
56 VF90443 DRAIN HOSE-38 1
57 VF83150 HOLDER,"U"HOSE 1
58 VF90701 17"COUNTER WEIGHT BLOCK 1
59 VF13534 WASHER 4
60 VF13519 WASHER,LOCK,Ø8 4
61 VF14067 SCREW M8*25 4
62 GT13054 SCEREW TM5x12 4
63 VF90814 BATTERY COVERY 1
64 VF90720 VACUUM MOTOR CONNECTION LINE 1
65 VF90730 SOLENOID VALVE CONNECTION LINE 1
66 VF90721 BRUSH MOTOR CONNECTION LINE 1
15
