Viper AS430C - Page 18

Item Part No. Description Qty
1 VF90203 SAFETY SWITCH KNOB 2
2 VF90286 SCREW KA3.5x12 4
3 VF90201 SAFETY SWITCH COVER LEFT 1
4 VV68303 SCREW KA3.5x15 4
5 VF90288 WASHER Φ3.6XΦ8X0.5 4
6 VF90210 SWITCH FIX FRAME 2
7 VV60153
SWITCH RL2
（ P ）
3
8 VF90009 DECAL CONTROL PANEL 1
9 VF90235 SCREW TM4x10 6
10 VF90204 17" SWITCH COVER 1
11 VF90706 24VDC REGULATOR BOARD 1
12 VA14584 SCREW PB3.0x8 4
13 VF90285 SWITCH SEAL STRIP 1
14 VF90216 SWITCH SEAL BUSHING 2
15 VF90202 SPRING 4
16 VF90252 SWITCH 2
17 VF90212 SAFETY SWITCH COVER RIGHT 1
18 VF90219 GASKET 2
19 VA13469 SCREW PB3x12 4
20 VF90213 SWITCH SEAL RING 2
21 GT13091 SCREW,PB3.5x9.5mm 2
22 VF89042-3 RELAY 1
23 GT13025 SCREW,M3X12 2
24 VF90725-1 RUNNING CAPACITOR 1
25 VF90815 COVER CONTROL HOUSING 1
26 GT13054 SCREW TM5x12 4
27 N/A 17" SERIAL NUMBER LABEL 1
28 GV70034 CLAMP DRAIN HOSE 1
29 VF14538 SCREW ST3.5x16 2
30 VF90027 BACK COVER PANEL 1
31 VF90129 SCREW M5x20 1
32 VF90113 HANDLE LIFT 1
33 VF14514 NUT LOCK M5 5
17
AS430C PART LIST
CONTROL SYSTEM AND ELECTRICAL SYSTEM
