Viper AS430C - Page 23

Item Part No. Description Qty
1 VF90729 BRUSH MOTOR KIT 1
2 VF90284 SOLENOID VALVE KIT 1
3 VF90418 SOLENOID VALVE BRACKET 1
4 VV13650A SCREW M4x10 4
5 VV20274 WASHER 2
6 VF90460 CONNECT PLATE C 1
7 VF90461 BRASS SPACER B 2
8 VF90421 SPACER 4
9 VF14555 SCREW,SHOULDER M12x50 4
10 VF14238 SCREW, M12x30 2
11 VF14530 SCREW,SHOULDER M6×40 2
12 VF85134 SPACER 2
13 VF85107 BUMPER ROLLER 2
14 VV13604 SCREW,SHOULDER M8x20 4
15 VF90406 17" BRUSH DECK 1
16 VF14506 NUT LOCK M6 2
17 GT13067 SCREW,SHOULDER M8x25 2
18 VF90465 DRIVEN PULLEY KIT 1
19 VF90424 NUT M20 2
20 VF90422 SPACER 1
21 ZD45425 BEARING 6204 LU 2
22 VF90423 CLAMP SLEEVE 1
23 VV13650A SCREW M4x10 2
24 VV20291 WASHER,LOCK,Ø4 2
25 VF90437 BRUSH SPRING CLIP 1
26 VF90463 DRIVEN PULLEY 1
27 VF90425 DRIVEN PULLEY SHAFT 1
28 VF90415 VIBRATION GASKET 1
29 VF13534 WASHER φ8.4x φ18x 2 1
30 VV20298 WASHER,LOCK,Ø8 1
31 VF90462 BELT 1
BRUSH SYSTEM
22
AS430C PART LIST
