TECHNICAL PARAMETERS
Parameter Type
Units
Model
AS6690T
AS7690T
AS7190TO
Solution tank capacity
L / Gal
85 L / 22 Gal.
Recovery tank capacity
L / Gal
90 L / 24 Gal.
Machine Length
mm/Inches
1490 mm/59 Inches
1550mm/61 Inches
1490 mm/59 Inches
Machine width with squeegee
mm/Inches
830 mm/33 Inches
950 mm/38 Inches
Machine width without squeegee
mm/Inches
730 mm/29 Inches
830mm/33 Inches
750mm/30 Inches
Machine Height
mm/Inches
1020 mm / 40 Inches
Working width
mm/Inches
660 mm / 26 Inches
760 mm / 30 Inches
710 mm / 28 Inches
Driving wheel diameter
mm/Inches
230 mm / 9 Inches
Driving wheel specific pressure on
the floor
N/mm
2
0.67 N/mm
2
Rear wheel diameter
mm/Inches
101 mm / 4 Inches
Rear wheel specific pressure on the
floor
N/mm
2
0.82 N/mm
2
Brush/Pad diameter
mm/Inches
330 mm x 2 /
13 Inches x 2
380mm x 2 /
15 Inches x 2
355x710 mm /
14x28 Inches
Brush/Pad pressure (max)
Kg/Lbs.
32 Kg /71 Lbs
41 Kg /90 Lbs
49 Kg /108 Lbs
35 Kg /77 Lbs
43 Kg /95 Lbs
51 Kg /112 Lbs
42 Kg / 93 Lbs
54 Kg / 120 Lbs
65 Kg / 143 Lbs
Solution Flow (max) per setting
L / Gal per minute
(0.9/1.5/2.2/3) Liters
(0.24/0.39/0.58/0.79) Gallons
(0.6/1.1/1.9/2.5) Liters
(0.16/0.29/0.5/0.66)
Gallons
Sound pressure level
dB (A)
69 ± 3 dB (A)
Sound pressure level in ECO mode or
in silent mode
dB (A)
65 ± 3 dB (A)
Handle Vibration Level (max)
m/s
2
< 2.5 m/s
2
Climbing capacity (max)
% grade
2%
Min. aisle turn
cm/Inches
155cm/61 Inches
165 cm/65 Inches
160 cm/63 Inches
Drive motor Power
Watt / H.P.
250 W / 0.33 HP
350 W / 0.47 HP
Working Speed
Km / Miles per hour
0 - 4.0 Km / 0 – 2.5 Miles per hour
0 – 3.2 Km / 0 – 2.0 Miles
per hour
Forward speed
Km / Miles per hour
0 - 4.0 Km / 0 - 2.5 Miles per hour
Reverse speed
Km / Miles per hour
0 - 2.0 Km / 0 - 1.25 miles per hour
Vacuum motor power
Watt / H.P.
500 W / 0.66 HP
Vacuum capacity
mm/In of H
2
O
1500 mm / 60 In of H
2
O
Vacuum capacity in ECO mode or in
silent mode
mm/In of H
2
O
900 mm / 35 In of H
2
O
Brush motor power
Watt / H.P.
500 x 2 Watt / 0.66 x 2 HP
750 Watt / 1.0 HP
Brush speed in normal mode
RPM
200 RPM
2200 RPM
Brush speed in ECO mode
RPM
160 RPM
1600 RPM
IP protection class
IP
IP24
Battery Compartment Size with Off -
board charger (L x W x H)
mm/Inches
(620 x 385 x 390) mm / 24.4 x 15.1 x 15.3 Inches
Battery Compartment Size with on-
board charger (L x W x H) (*)
mm/Inches
(535 x 385 x 390) mm / 21 x 15.1 x 15.3 Inches
Voltage
DC
24 V
Batteries (*)
Ah
N/A
Battery run time
(standard batteries) (*)
Hour
Up to 4 hours
On-Board Charger (*)
Volts/Amps
24V 25A
Productivity (max)
m
2
/h
2640 m
2
/h
3040 m
2
/h
2272 m
2
/h
Machine weight with empty tanks
(without batteries)
Kg/Lbs.
135 Kg / 298 Lbs.
138 Kg/304 Lbs.
148 Kg/326 Lbs.
Gross Vehicle Weight (GVW)
Kg/Lbs.
347 Kg / 765 Lbs.
350 Kg / 772 Lbs.
360 Kg / 794 Lbs.
Shipping Weight
Kg/Lbs.
202 Kg / 444 Lbs.
205 Kg / 451 Lbs.
215 Kg / 473 Lbs.
Packing dimensions (L x W x H)
mm/Inches
(1620 x 810 x 1200
mm) / (64 x 32 x 48
Inches)
(1660 x 910 x 1200 mm) /
(66 x 36 x 48 Inches)
(*): Optional

Viper AS7690T Specifications

General

Brand	Viper
Model	AS7690T
Category	Scrubber
Language	English
