28
ACCESSORIES/OPTIONS
In addition to the standard components, the machine can be equipped with the following accessories/options, according to the machine
specific use:
For further information concerning the above-mentioned optional accessories, contact an authorized Retailer.
ACCESSORIES/OPTIONS
See “Parts List” section
1. Brush of different materials
2. Battery tray
3. On-board charger
4. Blade of different materials
TROUBLESHOOTING
The motors do not work, error code
on display
The battery connector is disconnected.
Connect the battery connector.
The batteries are completely discharged.
The machine does not move
The machine has been turned on by using the ignition key
and by keeping one of the switches pressed.
Turn the ignition key to “0”, then try to start the
machine again without pressing the switches.
The recovery water vacuuming is
insufficient.
The recovery water tank is full.
The hose is disconnected from the squeegee.
The vacuum grid is clogged or the float is
stuck closed.
Clean the grid or check the float.
The squeegee is dirty or the squeegee blades
are worn or damaged.
Clean and check the squeegee.
The tank cover is not properly closed, or the gasket is dam-
aged, or the standpipe tube is clogged.
Close the cover correctly, or replace the gasket or
clean the Bend tube.
The vacuum hose is clogged.
The solution flow to the brushes is
insufficient.
The solution/clean water filter is dirty.
The squeegee leaves marks on the
floor.
There are debris under the squeegee blades.
The squeegee blades are worn, chipped or torn.
The squeegee has not been adjusted with the knob.
NOTE
If the machine is installed with the optional on-board charger, and when the on-board
charger is defective, the machine can not be operated. In case of battery charger malfunction, contact an au-
thorized Service Center.
