vision microsystems EPI 800 User Manual

SECTION 4: INSTALLATION REFERENCE 57
EPI800 Manual.doc EPI 800 MANUAL 2001 Vision Microsystems Inc.
TABLE 1: DPU Harness P1 Connector Wiring
Pin
Cable Connection
Device Conn.
Function
1
All cable shields
None
Shield System
2
BLK: Fuel Flow Cable
BLK: Fuel Flow
Fuel Flow
3
RED: Fuel Flow Cable
RED: Fuel Flow
4
WHT: Fuel Flow Cable
WHT: Fuel Flow
5
BLK: RPM Cable
BLK: RPM
RPM
6
RED: RPM Cable
RED: RPM
7
WHT: RPM Cable
WHT: RPM
8
N/U
9
N/U
10
N/U
11
N/U
12
BLK: Man. Pres. Cable
BLK: Man. Pres.
Man. Pres.
13
RED: Man. Pres. Cable
RED: Man. Pres.
14
GRN: Man. Pres. Cable
GRN Man. Pres.
15
WHT: Man. Pres. Cable
WHT: Man. Pres.
16
BLK: Oil Pres. Cable
Oil Pr Con. Pin 2
Oil Pres.
17
RED: Oil Pres. Cable
Oil Pr Con. Pin 4
18
GRN: Oil Pres. Cable
Oil Pr Con. Pin 3
19
WHT: Oil Pres. Cable
Oil Pr Con. Pin 1
20
Power Wire (20awg)
ACFT 3A Breaker
System Power
21
Inst. Dim. Wire (20awg)
ACFT Dimmer
Inst. Dimmer
22
Ground Wire (20awg)
ACFT Ground
System Ground
23
Volt Sense Wire (20awg)
ACFT +V (fused)
Volt Sensing
24
RED: Oil Temp. Cable
RED: Oil Temp.
Oil Temp.
25
BLK: Oil Temp. Cable
BLK: Oil Temp.
26
RED: OAT Cable
RED: OAT
OAT
27
BLK: OAT Cable
BLK: OAT
28
RED: CAT Cable
RED: CAT
CAT
29
BLK: CAT Cable
BLK: CAT
30
BLK: Amps Cable
BLK: Amps
Amps
31
RED: Amps Cable
RED: Amps
32
GRN: Amps Cable
GRN: Amps
33
WHT: Amps Cable
WHT: Amps
34
BLK: Fuel Pres. Cable
Fuel Pr Con. Pin 2
Fuel Pres.
35
RED: Fuel Pres. Cable
Fuel Pr Con. Pin 4
36
GRN: Fuel Pres. Cable
Fuel Pr Con. Pin 3
37
WHT: Fuel Pres. Cable
Fuel Pr Con. Pin 1
