vision microsystems EPI 800 User Manual

SECTION 4: INSTALLATION REFERENCE 70
EPI800 Manual.doc EPI 800 MANUAL 2001 Vision Microsystems Inc.
APPENDIX I: Specifications & Operating Conditions
ITEM
DESCRIPTION
DIMENSIONS
(in.)
WEIGHT
(oz.)
VOLTS
AMPSMAX.
(ma.)
OPER. TEMP
( Deg. C)
EPI 800 Indicator
(all 2 ¼ instruments)
2.5w x 2.8h x 1.0d
3
(internal
power)
3
-50 to +70
Data Processing Unit
6.4L x 5.0w x 2.7h
20
12v sys:
11 to15
320
-50 to +70
24v sys:
20 to 29
Fuel Level
Transducer
(8 foot length)
96L x ¾ tube
¾ NPT mtg.
21
(internal
power)
3
-50 to +70
Fuel Level
Transducer
(4 foot length)
48L x ¾ tube
¾ NPT mtg.
11
(internal
power)
3
-50 to +70
Average wire harness
(4 Cylinder )
N/A
11
N/A
N/A
-50 to +70

vision microsystems EPI 800 Specifications

General

Brand	vision microsystems
Model	EPI 800
Category	Control Systems
Language	English
