vision microsystems EPI 800 User Manual

SECTION 4: INSTALLATION REFERENCE 59
EPI800 Manual.doc EPI 800 MANUAL 2001 Vision Microsystems Inc.
TABLE 2: DPU Harness P2 Connector Wiring
Pin
Cable Connection
Device Conn.
Function
1
WHT: CHT 1 Cable
WHT: CHT 1
CHT 1
2
RED: CHT 1 Cable
RED: CHT 1
3
WHT: CHT 2 Cable
WHT: CHT 2
CHT 2
4
RED: CHT 2 Cable
RED: CHT 2
5
WHT: CHT 3 Cable
WHT: CHT 3
CHT 3
6
RED: CHT 3 Cable
RED: CHT 3
7
WHT: CHT 4 Cable
WHT: CHT 4
CHT 4
8
RED: CHT 4 Cable
RED: CHT 4
9
WHT: CHT 5 Cable
WHT: CHT 5
CHT 5
10
RED: CHT 5 Cable
RED: CHT 5
11
WHT: CHT 6 Cable
WHT: CHT 6
CHT 6
12
RED: CHT 6 Cable
RED: CHT 6
13
No Connection
14
YEL: EGT 1 Cable
YEL: EGT 1
EGT 1
15
RED: EGT 1 Cable
RED: EGT 1
16
YEL: EGT 2 Cable
YEL: EGT 2
EGT 2
17
RED: EGT 2 Cable
RED: EGT 2
18
YEL: EGT 3 Cable
YEL: EGT 3
EGT 3
19
RED: EGT 3 Cable
RED: EGT 3
20
YEL: EGT 4 Cable
YEL: EGT 4
EGT 4
21
RED: EGT 4 Cable
RED: EGT 4
22
YEL: EGT 5 Cable
YEL: EGT 5
EGT 5
23
RED: EGT 5 Cable
RED: EGT 5
24
YEL: EGT 6 Cable
YEL: EGT 6
EGT 6
25
RED: EGT 6 Cable
RED: EGT 6
NOTES:
1. Any position not used should be jumpered.
For example, if CHT 5 were not installed, then a jumper wire must
be installed between pins 9 and 10.
