Product Specifications
PRODUCT SPECIFICATIONS
Specifications E4100 D4100
Size
123/147mm(w/Flange) x 132mm(L) x 40mm(h), 370g
Ethernet Port
POE, UTP/STP 1000Mbps (8K Jumbo Frame required)
Protocol
IP, UDP, TCP, ICMP, IGMP
HDMI Port
19 pin type A female
RS232 Port
Phoenix Euro Block 3.81mm pitch - 5 pins
DC Jack (Power)
2.0/DC5V, 2A
Audio Jack (Line In/Out)
Phoenix Euro Block 3.81mm pitch - 4 pins
USB Port
Type-B USB2.0 Type-A USB2.0
LAN Bandwidth
850Mbps max. for each source
Max. Supported Timing
2160p 30Hz @60fps
Max. Distance
120m (UTP) between 2 devices (Encoder/Decoder/Ethernet Switch)
Built‐in Output Scaler
Downscale to 1/2
Upscale from horizontal
pixels < = 1920
Latency
~1 frame
~
17ms at 60 fps, ~33m at 30fps
Video Wall
Up to 8 x16 display
Image rotation (180/270°)
Accurate frame gap compensation
Tearing free
USB Redirection
KM over IP: dedicated for KVM application
USB
over IP: support any kind of USB HID devices
HDMI Audio Redirection
2 Ch LPCM 8 Ch LPCM 5.1 Ch NLPCM 7.1 Ch NLPCM
HDMI Audio Extraction
2 Ch LPCM (32KHz ~96KHz)
Stereo Audio Redirection
LINE IN (switch off HDMI audio) LINE OUT
RS232 Redirection
Transparent binary data transmission
HDMI 3D Support
HDMI 2.0 3D: TnB, SbS, F.P.
Compression Technology
Full Frame based visually lossless
video compression algorithm
Certificate
CE/FCC
Compliance
HDMI 2.0/HDCP 2.24/RoHS
Operating Temperature
0~70°C
Operating Humidity
10~85% RH (no condensation)
Storage Temperature
-10~80°C
Storage Humidity
5~95% RH (no condensation)
