UltraReceiver LD User Manual
Specification
Issue No: 2.01 Page: 12
Ref: ULRXLD-ASUM-700X Copyright © 2020 Vislink Technologies, Inc.
3.12.9. Alarm
Connector: LEMO 6-pin socket - EEF.0B.306.CLL
‘LEMO’ Type
Function
Pin 1
0v
Pin 2
NC
Pin 3
NC
Pin 4
Status output (open drain)
Pin 5
Reserved for future use
Pin 6
NC
Table 3-3 Alarm Pin Out
The Status output is an open-drain output.
When the system detects an alarm, it pulls low by default. It is also possible to
drive it manually via the menus (see Section 5.3.2) or the web page. Max Voltage
20V; Max Current 1A.
3.12.10. Ethernet – Control
Standard 10/100 Ethernet connection for control of the unit using Web Browser
(HTTP) and Network Management (SNMP).
If required, use the internal web browser link to download a copy of the units
SNMP MIB (Management Information Base).
NOTE: See Section 5.7 to connect to the unit via the internal web browser.
To ensure that the version relevant to the current code release is used, always
use the SNMP MIB link as the reference for any SNMP application.
To configure the unit via the inbuilt web page, see Section 5.7 to connect to the
unit.
