UltraReceiver LD User Manual
Receiver Setup
Issue No: 2.01 Page: 27
Ref: ULRXLD-ASUM-700X Copyright © 2020 Vislink Technologies, Inc.
6. Receiver Setup
The main functions that require configuration at the receiver are:
 Demodulation scheme in operation: LMS-T/DVB-T or ASI input – See Section 6.1.
 Type of down converter and operating frequency – See Section 6.2.
 Decoder – See Section 6.3.
6.1. Demodulation Options
The demodulator in the receiver can operate in three main types:
1. Single Pedestal LMS-T(S)
2. Dual Pedestal LMS-T(D) (if licensed)
3. DVB-T (if licensed)
Demodulation options are selected in the DEMODULATOR > INPUT Menu. You
can select either LMS-T or DVB-T.
Select the demodulator type and bandwidth from the DEMODULATOR > INPUT
> Demod type menu.
Select the Bandwidth from DEMODULATOR > INPUT > Bandwidth menu.
NOTE: When using dual pedestal bandwidths in LMS-T mode, the bandwidth
shown is the combined width of the two pedestals.
The LMS-T bandwidths:
 Single Pedestal:
 3, 4, 5, 6, 7, 8, 10, 12 MHz
 Dual Pedestal:
 4, 6, 8, 10, 12, 14, 16, 20 & 24 MHz
The DVB-T bandwidths:
 6, 7 & 8 MHz
NOTE: After any change, a screen stating “ Please Wait ” displays while the unit
loads the new settings.
