Page.36.
When the image is enlarged, if not operate on touch screen, it can operate by the
keyboard ,press the key to zoon in , press the key to zoom out ,press upward
and downward key to move image .
If it is network video input to the tester, as the tester supports resolution up to 1080p, the
input image will be very clear after it is enlarged. This is greatly helpful for the installers to
ensure the IP camera’s video coverage and decide the IP camera’s install site.
Image can only be enlarged on SD mode (The icon “ONVIF”is SD mode.)
IP camera video settings: Click “Video Set” to enter the IP camera’s encoder and resolution
settings. Make the desired changes and click “OK “to save.
Image setting: Click “Imaging Set” to adjust image brightness, saturation, contrast, sharpness
and backlight compensation mode.
.
